Copper Knitted Mesh
Copper knitted mesh is a knitted with 99.9% pure copper wire, a production process that produces an extremely strong and flexible tubular fabric consisting of a series of interlocking rings, which is then pressed into continuous lengths and rolled up for packaging. It is softer than similar stainless steel knitted mesh, and it is also resistant to atmospheric corrosion, but it is subject to oxidants (such as nitric acid, chlorine) iron, fluoride and amino acid compounds) erosion. It has high thermal conductivity and ductility, electrical conductivity. Therefore, it is widely used as an RFI shield, in Falzer cages, roofing, HVAC and many electric-based applications. Anping Guangtong Hardware Wire Mesh Co., Ltd. is very proud to have one of the most complete inventory of copper knitted mesh, and has the most advanced production workshop,equipment and R & D team, with the advantage of oil-free weaving. If you are interested in further discussing the technical details of the copper knitted mesh or cooperation opportunities, please feel free to contact us.
Copper Knitted Mesh Specifications
Specification of Round Wire Knitted Mesh Type Wire Diameter(mm) Width (mm) Number of Stitches Per cm on Length Number of Stitches Per cm Across Lay Flat Fine Mesh 0.08-0.18 6-300 3.5 4.4 Medium-Fine Mesh 0.16 40-600 2.4 3.5 Standard Mesh 0.08-0.35 30-1000 1.6 1.9 Coarse Mesh 0.25-0.40 30-1000 1.6 0.74 Super Coarse Mesh 0.4-0.5 100-350 0.5 0.5 Specification of Specification of Flat Wire Knitted Mesh Wire Diameter (mm) Mesh Opening/Loop Size(mm) Number of Needles Maximum Width (mm) Minimum Width (mm) 0.1×0.3 2×4 36 60 55 0.1×0.3 4.5×4,2.5×4 34 150 100 0.1×0.4 4.5×5.5,2.5×5.5 40 150 120 0.1×0.4 4×3.5,2.5×3.5 56 205 180 0.1×0.4 4×4,3×4 65 260 240 0.2×0.4 5.2×3.5,3×3.5 94 420 380 0.2×0.4 7.5×5,5×5 102 565 490 0.2×0.5 5×4,2.5×4 128 560 470 Copper Knitted Mesh Features and Advantages
Clean mesh: our factory introduces advanced technology, using oil-free weaving, the production of copper knitted mesh has the characteristics of clean mesh and uniform mesh;
Corrosion resistance, high temperature resistance: excellent performance in seawater and other highly corrosive media. It can maintain good corrosion resistance in a variety of acids, alkalis, salt solutions and organic acids, and it smelting point is as high as 1083'C. This feature enables copper vapor-liquid mesh to maintain stable performance in high temperature environments and is suitable for various high temperature industrial processes;
Electrical conductivity, thermal conductivity: copper as an excellent conductive material, its electrical conductivity mainly from its internal free electrons. In the metal lattice, these free electrons can move freely to form a current, which promotes the copper knitted mesh to have high-quality electrical and thermal conductivity;
Easy to process: copper knitted mesh because of its unique processing technology, so that it has strong and flexible characteristics, easy to cut, bending, stretching and other industrial processing.
Copper Knitted Mesh type
Copper Knitted Mesh material: copper;
copper Knitted Mesh wire type: round wire, flat wire;
copper Knitted Mesh strand type: single strand, multi-strand;
copper Knitted Mesh surface type: flat type, crimped type.
Copper Knitted Mesh Production Capacity
Anping Guangtong Hardware Wire Mesh Co., Ltd. is a professional design, research and development, production, custom knitted mesh manufacturer, with more than 20 years of experience in the production and processing of knitted mesh, plant covers an area of 40,000 square meters, annual output value of $21 million, annual capacity of 36 million square meters, with independent research and development team, the introduction of advanced knitted mesh equipment, Ultra-modern production workshop, leading the knitted mesh production and processing industry, has reached strategic partnerships with more than 60 countries in the world, we welcome inquiries and sample requests.
(If we don't have what you need, or if you need a reliable long-term source throughout your supply chain, we can customize it to your copper knitted mesh specifications.)
Copper Knitted Mesh Industry Certificate
The company has obtained and fully implemented ISO9001 Quality Management System Certification, ISO45001 Occupational Health And Safety Management System Certification, ISO14001 Environmental Management System Certification, IATF16949 Automotive Industry Quality Management System Certification, AEO customs certification and other related certifications.
Copper Knitted Mesh Packaging
Inner paper tube & Carton box & Plywood case
Copper Knitted Mesh Applications
Filtration: knitted is commonly used as a filtration medium in various industries such as petrochemical, pharmaceutical and food processing to remove impurities from liquids and gases.
Sealing: knitted mesh is highly compressible and flexible, making it an ideal material for sealing applications in the automotive, aerospace and other industries to prevent liquid and gas leaks.
Catalytic action: knitted mesh is also used as a substrate for catalytic converters in automotive exhaust systems, helping to reduce harmful emissions and improve fuel efficiency.
EMI Shielding: knitted wire mesh is an excellent electromagnetic interference (EMI) and radio frequency interference(RF) shielding material, making it ideal for use in electronic devices, shielding rooms, and other applications where electromagnetic interference needs to be minimized.
Petroleum
Chemical industry
Pharmaceutical Manufacturing
EMI Shielding
Car
Aerospace aviation
FAQ
What is the minimum order quantity of your knitted wire mesh?
✔ Please request a quote from our Customer Service team at sales@guangtongwiremesh.com. Delivery time and minimum order quantity will be included in the quotation.
What size tape should l order? How much should l buy?
✔ For specific tape packaging, please contact us and we can provide professional brass mesh tape samples.
Can you provide relevant documents?
✔ Yes, we can provide all relevant export documents (commercial invoice, packing list, original, etc.) and other required documents (Certificate of materials, Declaration of origin, etc.).
Can you guarantee the safe and reliable delivery of your copper knitted mesh?
✔ Yes, we always use high quality export packaging, and we also use specialized dangerous goods packaging for dangerous goods and verified refrigerated shippers for temperature-sensitive items. Professional packaging and non-standard packaging requirements may incur additional costs.
What is the production capacity of your company? Can the quality be guaranteed?
✔ Yes, we have introduced advanced knitted mesh production line to ensure that it is produced in a dry and suitable temperature environment, which can ensure the output and quality of copper knitted wire mesh.
